| Type of Product | Programmable Controller Power Supply |
| Model No | CS1D-PD025 |
| Type | DC power supply unit |
| Power Consumption | 60W or less |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Programmable Controller Power Supply |
Model No |
CS1D-PD025 |
Type |
DC power supply unit |
Power Consumption |
60W or less |
Storage Temperature |
-20 to +75℃ (excluding battery) |
Country of Origin |
Japan |
Monotaro ID |
46389454 |
Ambient Humidity to Use |
10 to 90% RH (no condensation) |
Output Capacity |
DC5V 5.3A (including supply to CPU unit) DC26V 1.3A Total 40W |
Pack of |
1 Pcs |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Mass (Kg) |
(Each device) 6 or less |
Specifications |
No output during operation |
Operation Ambient Temperature (°C) |
0 to 55 |
Inrush current (A) |
30 or less |
Structure |
Built-in type in the panel |
Insulation Resistance (MOhm) |
Between DC external terminals and GR terminal / 20 mohm or more (at 500 V DC) |
Applicable Standard |
cULus (Class I Div2 Hazardous Location Certified Product), NK, Lloyd, EC Directive |
Allowable Voltage Range |
DC19.2 to 28.8 V |
Output Terminal |
(Power) None |
Atmosphere |
No corrosive gas |
Noise Resistance |
Compliant with IEC61000-4-4 2kV (power line) |
Ground Clearance |
Class D grounding (Class 3 grounding) |
Power Supply Voltage |
DC24 |
Shock Resistance (m/s²) |
Compliant with JIS C 60068-2-27 147 X, Y, Z 3 times in each direction |
Shock Resistance |
Compliant with JIS C 60068-2-6 10 to 57 Hz amplitude 0.075 mm, 57 to 150 Hz acceleration 9.8 m/s² X, Y and Z directions 80 min each (8 min sweep timex10 sweep times = 80 min total) |
Import Country |
Direct Import from Japan |
