Ships within 15 days
View
View
View
View
| Model No | ULN2803A |
| Type of Product | Octal NPN Motor Driver IC |
| Width | 7.1 mm |
| Height | 3.93 mm |
Model No |
ULN2803A |
Type of Product |
Octal NPN Motor Driver IC |
Width |
7.1 mm |
Height |
3.93 mm |
transistor Type |
NPN |
Dimension |
23.24x7.1x3.93 mm |
Mounting Type |
Through Hole |
Country of Origin |
USA |
Pack of |
20 Pcs |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Number of Elements Per Chip |
8 |
Maximum Emitter Base Voltage |
50 V |
Maximum Collector Emitter Saturation Voltage |
1.1 V |
Length |
23.24 mm |
DC Current Gain |
Minimum: 1000 A |
Maximum Continuous Collector Current |
500 mA |
Maximum Operating Temperature |
+85°C |
Maximum Collector Emitter Voltage |
50 V |
Transistor Configuration |
Common Emitter |
Package Type |
PDIP |
Minimum Operating Temperature |
-20°C |
Pin Count |
18 |
