| Type of Product | Pressure Regulator |
| Model No | R600-04 |
| Thread Type | RC |
| Country of Origin | Japan |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Pressure Regulator |
Model No |
R600-04 |
Thread Type |
RC |
Country of Origin |
Japan |
Monotaro ID |
35807922 |
Main Unit Material |
Aluminum Die Casting |
Maximum Operating Pressure (MPa) |
0.93 |
Suitable Fluid |
Air |
Operating Temperature Range |
5～60° C |
Pipe Connection Diameter |
1/2 inch |
Mass |
320 g (with pressure gauge) |
Lubrication |
Unnecessary |
Overall Length (mm) |
124 mm |
Pressure Setting Range |
0.05～0.83 MPa |
Pressure Gauge |
With pressure gauge |
Pressure Resistance |
1.47 MPa |
Accessories Included |
Bracket / Pressure gauge G1-40 (Φ40 × 1MPa) |
Exhaust |
Non-Relief Type |
Set Pressure Unit |
MPa |
Type of Sign |
With bracket |
Name of Manufacturer/Packer/Importer |
Koganei Corporation |
Pipe Connection Size |
12.7 mm |
