Ships within 20 days
View
View
View
View
| Type of Product | Pressure Sensor |
| Accuracy | ±0.5%FS |
| Country of Origin | China |
| Maximum Operating Temperature | 85°C |
Type of Product |
Pressure Sensor |
Accuracy |
±0.5%FS |
Country of Origin |
China |
Maximum Operating Temperature |
85°C |
Mounting Type |
Threaded |
Minimum Operating Temperature |
-30°C |
Maximum Pressure Reading |
1 bar |
Supply Voltage |
9 to 30 V DC |
Housing Material |
Stainless Steel |
Series |
M20 |
Electrical Connections |
Angular DIN175301-803A |
Process Connection |
G1/4A ISO 1179-2 |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Minimum Pressure Reading |
0 bar |
Pressure Reading Type |
Gauge |
Media Measured |
Air, Fluid, Mixed Oil, Water |
Analogue Outputs |
4 to 20 mA |
