| Type of Product | Digital Pressure Switch |
| Model No | ISE20A-V-01-JA1 |
| Application | Positive Pressure [-0.1 to 1.0 MPa] |
| Port size | 3.175 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Digital Pressure Switch |
Model No |
ISE20A-V-01-JA1 |
Application |
Positive Pressure [-0.1 to 1.0 MPa] |
Port size |
3.175 mm |
Standard |
CE |
Connection Type |
Male thread |
Body Material |
Resin + Metal |
Display |
Digital |
Power Supply Voltage |
12 to 24 V DC ±10% |
Operating Humidity Range |
35~85% |
No. Of Output |
3 |
Power Supply Type |
DC |
Fluid Type |
Noncorrosive / Incombustible Air |
Drive Configuration |
Digital |
No. Of Inputs |
1 |
Protection Structure |
IP40 |
Accessories |
Lead wire with connector (lead wire length 2 m, 5 cores) + bracket A (vertical mounting) |
Operating Temperature Range |
-5~50° C |
Unit Specification |
With unit conversion function |
Lamp |
Available |
Thread Type |
R |
Output Method |
PNP Open Collector |
Analog Output |
Current |
Pressure Resistance |
1.5 MPa |
