| Model No | PFC-4921-RAF |
| Display | Numerical display: Instantaneous display, upper row 6 digits, 7 segment LED, character height 14.2 mm / Accumulative display, lower row 8 digits, 7 segment LED, character height 10.16 mm |
| Type of Product | Digital Panel Meter |
| Function | Scaling: Any rate can be set for one pulse |
Model No |
PFC-4921-RAF |
Display |
Numerical display: Instantaneous display, upper row 6 digits, 7 segment LED, character height 14.2 mm / Accumulative display, lower row 8 digits, 7 segment LED, character height 10.16 mm |
Type of Product |
Digital Panel Meter |
Function |
Scaling: Any rate can be set for one pulse |
Country of Origin |
Japan |
Input Method |
Single phase/two phase signal |
Storage Temperature Range |
- 20 to + 70 ℃ |
Monotaro ID |
66272958 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
COCO RESEARCH |
Input Power |
AC 100-240 V |
Specifications |
●Analog: ±10V●Zero display: Leading zero suppression●Dynamic prediction function: 9 levels (including continuous prediction and periodic hold)●Memory contents and storage method: Set value, accumulated count value (when backup function is ON)/EEPROM (non-volatile memory)●Measurement value: Instantaneous value (speed), accumulated value●Update time (m): 1●Instantaneous calculation function: Moving average function 1 to 8●Accumulation range: Maximum number of pulses input ±47bit. Internal count stops at maximum pulses or more. |
Operating Temperature / Humidity Range |
0℃ to +40℃ / 85%HR or less (no condensation) |
Power Consumption (VA) |
AC power specifications: 8 or less, DC power specifications: 6 or less |
Atmosphere |
Surrounding area: No corrosive gases |
