| Model No | K3HB-RPB-A AC100-240 |
| Type of Product | Rotational Pulse Meter |
| Display Type | Negative Type LCD (Backlit LED) Display, 7-Segment Digital Display |
| Input Type | PNP |
Model No |
K3HB-RPB-A AC100-240 |
Type of Product |
Rotational Pulse Meter |
Display Type |
Negative Type LCD (Backlit LED) Display, 7-Segment Digital Display |
Input Type |
PNP |
Country of Origin |
Japan |
Included Components |
Waterproof packing, 2 fixtures, terminal cover, unit seal, instruction manual |
Operating Temperature Range |
-10 to +55℃ |
Monotaro ID |
39076545 |
Import Country |
Direct Import from Japan |
No. of Digits |
5 digits (-19999 to 99999) |
Power Consumption |
18VA or less |
Type of Sign |
Panel Mounting |
Protection Class |
Front: NEMA4X Indoor Compliant (IP66 Equivalent), Rear Case: IP20, Terminal Section: IP20+ Finger Protection (VDE0106/100) |
Applicable Standard |
UL61010-1, CSA C22.2 No.1010.1 (Evaluated by UL), EN61010-1 (IEC61010-1) Pollution degree 2/Overvoltage category II EN61326: 1997, A1: 1998, A2: 2001 |
Measurement accuracy |
(at23±5?) Function F1, F6: ±0.006%rdg±1 digit (when the sensor is voltage pulse/open collector type) Function F2 to F5: ±0.02%rdg±1 digit (sensor is voltage pulse/open collector type) time of type) |
Series |
K3HB-R Series |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Mass (g) |
About 300 |
Input Power |
AC100 to 240 50/60 Hz |
Mass of Main Unit (g) |
About 300 |
Withstand Voltage |
AC2300V 1min (between external terminals and case) |
Category |
Programmable Digital Panel Meter |
Power Supply Voltage (V) |
AC/DC 24 V |
