| Type | DC fan |
| Type of Product | DC Propeller Fan |
| Features | Standard |
| Shape | Square |
Type |
DC fan |
Type of Product |
DC Propeller Fan |
Features |
Standard |
Shape |
Square |
Model No |
MDA625Y-24L |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Oriental Motor Co., Ltd. |
Thickness (mm) |
25 |
Import Country |
Direct Import from Japan |
Monotaro ID |
68036091 |
Connection Type |
With extension cable |
Frame Material |
Polycarbonate (flame retardant grade V-0) |
Mounting Hole Spacing, Square (mm) |
62x62 |
Additional Functions |
Pulse sensor type |
Current (A) (50/60Hz) |
0.1 |
Maximum Static Pressure (Pa) |
49 |
Maximum Airflow |
0.5 m³/min |
Sound Pressure Level (dB) |
30 |
Speed Type |
Standard speed |
Material (Fan Blade) |
Polycarbonate (flame retardant grade V-0) |
Input Voltage (V) |
DC24 |
Fan |
MD625B-24SH |
Set Contents |
Fan, finger guard, mounting screw (M3X40mm), extension cable, instruction manual |
Rated Rotation Speed (min⁻¹ [rpm]) |
4000 |
Protection |
Built-in burnout prevention circuit |
RoHS Directive |
Correspondence |
