| Type | DC fan |
| Type of Product | DC Propeller Fan |
| Features | Standard |
| Shape | Square |
Type |
DC fan |
Type of Product |
DC Propeller Fan |
Features |
Standard |
Shape |
Square |
Model No |
MDS1238H-24 |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Oriental Motor Co., Ltd. |
Thickness (mm) |
38 |
Import Country |
Direct Import from Japan |
Monotaro ID |
1049886 |
Frame Material |
ABS+PBT(UL94V-0) |
Mounting Hole Spacing, Square (mm) |
120x120 |
Additional Functions |
None |
Current (A) (50/60Hz) |
1.5 |
Maximum Static Pressure (Pa) |
360 |
Maximum Airflow |
6.35 m³/min |
Sound Pressure Level (dB) |
64 |
Speed Type |
high speed |
Material (Fan Blade) |
PPE+PS(UL94V-1) |
Input Voltage (V) |
DC24 |
Rated Rotation Speed (min⁻¹ [rpm]) |
6400 |
