| Type of Product | Leakage Protection Relay |
| Model No | RRD12AZ3-2/5-V2 |
| Rated Current (A) | 1200 |
| Country of Origin | Japan |
Type of Product |
Leakage Protection Relay |
Model No |
RRD12AZ3-2/5-V2 |
Rated Current (A) |
1200 |
Country of Origin |
Japan |
Detection Method |
Earth leakage: Electronic/current operated type |
Power Consumption (VA) |
0.5 (operating 2 |
Monotaro ID |
50217002 |
Rated Voltage (V) |
max. 600[50/60Hz] (main circuit) |
Import Country |
Direct Import from Japan |
Rated Sensitivity Current (mA) |
200/500 switch |
Control Voltage |
200/220 V |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
No. of Pole |
3 Pole |
Contact Configuration |
2C (Built-In) |
Rated Operating Current |
50% of rated sensitivity flow rate |
Frame (AF) |
(Ampere) 1200 |
Earth Leakage Indication |
Electric type (LED display) |
Mass (Kg) |
15.7 |
Retention |
Contact: Electrical retention |
Rated Input Current (A) |
10 (AC200 V), 6 (AC415 V) (built-in) [L load] |
Working Voltage |
160 to 242 V |
Breaking Current (A) |
5(AC200V/AC100V/DC24V COSΦ=1), 3(AC200V/AC100V COSΦ=0.3 to 0.4 L/R=0.007), 2(DC24V COSΦ=0.3 to 0.4 L/R=0.007) |
Electric system |
1Φ3 W, 3Φ3 W, 3Φ4 W |
Type of Resetting |
Press the Reset Button or Turn off the Control Power. |
Continuous Current (A) |
5 (built-in) |
Inertia Non-Operation Time |
Operating time set valuex0.5 Sec or more (at test current of 10A) |
