| Model No | AR001 |
| Type of Product | Proximity Switch |
| Country of Origin | Japan |
| Case Material | Heat resistant ABS |
Model No |
AR001 |
Type of Product |
Proximity Switch |
Country of Origin |
Japan |
Case Material |
Heat resistant ABS |
Monotaro ID |
22183123 |
Insulation Resistance |
DC250V (20MΩ or more with mega / between cases) |
Sensor Shape |
Square |
Head Shape |
Square |
Ambient Humidity to Use |
20 to 80%RH |
Name of Manufacturer/Packer/Importer |
ASA ELECTRONICS INDUSTRY |
Import Country |
Direct Import from Japan |
Withstand voltage (V / min) |
AC1000 (between live parts and case) |
Detection Area |
Iron |
Output Current (mA) |
15MAX |
Operations |
OFF-ON |
Cable |
3-core Φ2.8x1m, gray |
Power Supply Voltage (V) |
DC 5 to 24 |
Operating Ambient Humidity (% RH) |
20 to 80 |
Detection Distance (mm) |
(Iron wire Φ2) 1, (Iron □30xt1) 2 |
Current Consumption (mA) |
12MAX |
Indicator Lamp |
None |
Output Specifications |
NPN open collector (ON when approaching) |
Operation Ambient Temperature (°C) |
-20 to 85 (no condensation) |
Directions |
Magnetic detection: Upward |
