Ships within 19 days
View
View
View
View
| Model No | AR002 |
| Type of Product | Proximity Switch |
| Protection Class | IP65 |
| Country of Origin | Japan |
Model No |
AR002 |
Type of Product |
Proximity Switch |
Protection Class |
IP65 |
Country of Origin |
Japan |
Case Material |
GF reinforced PBT |
Monotaro ID |
22183132 |
Insulation Resistance |
DC250V (20MΩ or more with mega / between cases) |
Sensor Shape |
Square |
Head Shape |
Square |
Ambient Humidity to Use |
20 to 80%RH |
Name of Manufacturer/Packer/Importer |
ASA ELECTRONICS INDUSTRY |
Import Country |
Direct Import from Japan |
Withstand voltage (V / min) |
AC1000 (between live parts and case) |
Detection Area |
Iron |
Output Current (mA) |
12MAX |
Operations |
OFF-ON |
Cable |
3-core Φ2.8x1m, gray |
Power Supply Voltage (V) |
DC 5 to 24 |
Operating Ambient Humidity (% RH) |
20 to 80 |
Detection Distance (mm) |
(Iron□30xt10)6, (Iron□30xt2)4 |
Current Consumption (mA) |
15MAX |
Indicator Lamp |
Red |
Output Specifications |
NPN open collector (ON when approaching) |
Operation Ambient Temperature (°C) |
-20 to 85 (no condensation) |
Directions |
Magnetic detection: Upward |
Mounting |
M3 Tightening torque 0.3 Nm |
