| Type of Product | Timing Pulley |
| Model No | P40-H-150B |
| Material | Steel |
| Country of Origin | Japan |
Type of Product |
Timing Pulley |
Model No |
P40-H-150B |
Material |
Steel |
Country of Origin |
Japan |
No. of Teeth |
40 |
Dimension LB (mm) |
65 |
Type |
H150 B Type |
Dimension LA (mm) |
45 |
Monotaro ID |
35269272 |
Pitch Diameter (Φmm) |
161.7 |
Dimension K |
20 mm |
Shaft Hole Diameter d (mm) |
20-52 mm |
Dimension D (Φmm) |
88 mm |
Suitable Flange |
F-16168150 |
Suitable Belt Width (mm) |
38.1 |
Compatible Belt |
H |
Outer Diameter |
160.33 mm |
Tooth width W (mm) |
40 |
Dimension H |
2.5 mm |
Pulley |
B Type |
Name of Manufacturer/Packer/Importer |
Mitsuboshi belting Ltd |
Import Country |
Direct Import from Japan |
