| Type of Product | Complete Timing Pulley |
| Model No | S2-44S5M0150BF-30T3K |
| Country of Origin | Japan |
| No. of Teeth | 44 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Complete Timing Pulley |
Model No |
S2-44S5M0150BF-30T3K |
Country of Origin |
Japan |
No. of Teeth |
44 |
Dimension LB (mm) |
34 |
Type |
Starquick S5M |
Dimension LA (mm) |
22 |
Monotaro ID |
58502787 |
Dimension K |
12 mm |
Dimension H |
2.5 mm |
Surface Treatment |
Black dyed |
Finish Processing |
2 Taps (on Key / 120° Position) |
Dimensions PD (mm) |
70.03 |
Keyway height h (mm) |
3.3 |
Shaft Hole Diameter (mm) |
30 mm |
Material (Pulley) |
Steel |
Shape |
With Flange |
Dimension OD (mm) |
69.07 |
Dimension M |
53 mm |
Dimension W |
17 mm |
Keyway width B (mm) |
8 |
Dimension F |
74 mm |
Dimension d |
50 mm |
Name of Manufacturer/Packer/Importer |
Mitsuboshi belting Ltd |
