| Type of Product | Timing Pulley |
| Model No | A4-60S5M0100AF-19T3K |
| Material | Aluminum |
| Country of Origin | Japan |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Timing Pulley |
Model No |
A4-60S5M0100AF-19T3K |
Material |
Aluminum |
Country of Origin |
Japan |
No. of Teeth |
60 |
Dimension LA (mm) |
16 mm |
Monotaro ID |
58481342 |
Compatible Belt |
S5M |
Dimension H |
2.5 mm |
Surface Treatment |
Anodized (White) |
Finish Processing |
2 Taps (On Key / 120° Position) |
Dimensions PD (mm) |
95.49 mm |
Keyway height h (mm) |
2.8 mm |
Shaft Hole Diameter (mm) |
19 mm |
Shape |
With Flange |
Dimension OD (mm) |
94.53 mm |
Dimension M |
78 mm |
Dimension W |
11 mm |
Keyway width B (mm) |
6 mm |
Dimension F |
99 mm |
Nominal Width (mm) |
10 mm |
Series |
Star Quick |
Name of Manufacturer/Packer/Importer |
Mitsuboshi belting Ltd |
