| Model No | DOL 7212 |
| Type of Product | Digital DOL Starter Instrument |
| Current Range | Adjustable Overload: 0–30A, Adjustable Dry Run: 0–30A |
| Country of Origin | India |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Model No |
DOL 7212 |
Type of Product |
Digital DOL Starter Instrument |
Current Range |
Adjustable Overload: 0–30A, Adjustable Dry Run: 0–30A |
Country of Origin |
India |
Display |
Digital Voltage Display, Digital Current Display |
Suitable For |
Any Hp Motor (User Can Connect Any Contactor Rating To Design Dol Starter |
Dimension |
72x72 mm |
Package Contains |
1 × Digital DOL Instrument, 1 × 50A CT, 2 × Mounting Clamps |
Timer |
Auto/Manual Mode, Auto Reset, Auto Bypass, Auto Switch, Cyclic Timer (0–999 min), Delay Off Timer (0–999 min), On/Off Delay Timer (0–999 min), Auto Switch Timer (0–999 sec) |
Name of Manufacturer/Packer/Importer |
Mivan Technologies |
Input Voltage |
415 VAC (R, Y, B) |
Output Voltage |
Potential Free Relay Output |
Protection Features |
High/Low Voltage (adjustable), Overload Protection, Dry Run Protection, Short Circuit, Phase Failure, Phase Interchange, Voltage Imbalance, Protection Bypass |
