| Monotaro ID | 46384082 |
| Type of Product | Digital I/O Slave Clamp Type |
| Model No | CRT1-MD16SL-1 |
| Storage Temperature | -25 to 65℃ |
Monotaro ID |
46384082 |
Type of Product |
Digital I/O Slave Clamp Type |
Model No |
CRT1-MD16SL-1 |
Storage Temperature |
-25 to 65℃ |
Vibration Resistance |
10 to 60Hz double amplitude 0.7 mm/60 to 150Hz 50( m/s² )/80min each in X, Y, and Z directions |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Ambient Humidity to Use |
25 to 85% (non-condensing) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Specifications |
●Terminal block screw tightening torque (N m): 0.5 (M3 (connection screw)), 0.5 (M3 (mounting screw)) ●Internal I/O common wire processing: PNP compatible ●Power supply type: Multi power supply type ●Ambient atmosphere for use: No corrosive gas ●Mounting method: Mounting using DIN35mm rail, M4 screws, or mounting brackets (varies depending on model) |
Insulation Type |
Photocoupler insulation |
Insulation Resistance (MOhm) |
20 or more (between isolated circuits) |
No. of Circuits |
8 points / common |
Communication Power Supply Voltage |
DC 14 to 26.4 V |
Withstand Voltage |
500 V AC (between isolated circuits) |
Input Display |
LED display (yellow) |
Storage Humidity (%) |
25 to 85 (no condensation) |
Delay Time |
1.5 ms or Less (ON), 1.5 ms or Less (OFF) {input section} / 0.5 ms or Less (ON), 1.5 ms or Less (OFF) {output section} |
I/O Power Supply Voltage (V) |
DC 20.4 to 26.4(DC 24V-15 to +10%) |
Noise Resistance |
Compliant with IEC61000-4-4 2 kV (power line) |
Number of Input/Output Points |
8 points |
Operation Ambient Temperature (°C) |
-10 to 55 |
Shock Resistance (m/s²) |
150 (3 times for 6 directions in 3 axes) |
Leakage Current (mA) |
0.1 or less |
