| Model No | DT33 220V 0.75kW 4.2A |
| Color | Munsell N5.5 |
| Type of Product | Push Button Switch |
| Vibration Resistance | Frequency 16.7Hz Double amplitude 3mm |
Model No |
DT33 220V 0.75kW 4.2A |
Color |
Munsell N5.5 |
Type of Product |
Push Button Switch |
Vibration Resistance |
Frequency 16.7Hz Double amplitude 3mm |
Type |
Exposed / with overload protection |
Terminal Screw |
M4 (self-up terminal) |
Shock Resistance |
100m / S <sup>2</sup> (about G10) |
No. of Buttons |
2 |
Mass (g) |
280 |
Monotaro ID |
35172496 |
Relative Humidity |
45% to 85% |
Country of Origin |
Japan |
Case Material |
plastic |
Letters on Button |
ON (black), OFF (red) |
Rated Operating Current (A) |
4.2 |
Rated Capacity (kW) |
0.75 |
Opening / Closing Life (times) |
Electrical switching / 100,000 (220V AC, rated current 16A, switching frequency 10 times / min) |
Conformed Standard |
Electrical Appliance and Material Safety Law |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Dainichi Seisakusho Co., Ltd. |
Insulation Resistance (MOhm) |
(Between electrical circuit and box side) 10 or more |
Compatible Cable |
2 mm² |
Ambient Temperature (℃) |
-10 to 50 |
Reference Ambient Temperature |
40℃ |
Overcurrent Tripper Type |
Thermal method |
Where to Use |
Avoid using the product in abnormal ambient conditions such as dust, smoke, corrosive gas, steam, and salt. |
