| Model No | DF33 220V1.5 kW 7.3A |
| Color | Munsell N5.5 |
| Type of Product | Push Button Switch |
| Vibration Resistance | 16.7Hz Double amplitude 3mm |
Model No |
DF33 220V1.5 kW 7.3A |
Color |
Munsell N5.5 |
Type of Product |
Push Button Switch |
Vibration Resistance |
16.7Hz Double amplitude 3mm |
Protection Class |
IP40 (panel surface) |
Type |
Back connection type / with overload protection |
No. of Buttons |
2 |
Mass (g) |
220 |
Monotaro ID |
46778216 |
Button Color |
ON (black), OFF (red) |
Motor Capacity (kW) |
1.5 |
Country of Origin |
Japan |
Case Material |
Plastic, switch unit: polyphenylene oxide, phenolic resin |
Letters on Button |
ON (black), OFF (red) |
Rated Operating Current (A) |
7.3 |
Rated Capacity (kW) |
1.5 |
Opening / Closing Life (times) |
Electrical switching / 100,000 (220V AC, rated current 16A, switching frequency 10 times / min) |
Conformed Standard |
Compliant with Electrical Appliance and Material Safety Law |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Dainichi Seisakusho Co., Ltd. |
Insulation Resistance (MOhm) |
(Between electrical circuit and outer box) 10 or more |
Rated Frequency (Hz) |
50/60 |
Specifications |
● Allowable installation angle: 10° forward/backward and 90° left/right relative to the vertical plane |
Cover Material |
ABS resin |
Reference Ambient Temperature |
40℃ |
Overcurrent Tripper Type |
Thermal method |
