| Model No | DTW33 220V 0.1kW 0.9A |
| Color | Munsell N5.5 |
| Type of Product | Push Button Switch |
| Vibration Resistance | Frequency 16.7Hz Double amplitude 3mm |
Model No |
DTW33 220V 0.1kW 0.9A |
Color |
Munsell N5.5 |
Type of Product |
Push Button Switch |
Vibration Resistance |
Frequency 16.7Hz Double amplitude 3mm |
Protection Class |
IP65 |
Type |
Exposed / With overload protection / Waterproof |
Terminal Screw |
M4 (self-up terminal) |
Shock Resistance |
100m / S <sup>2</sup> (about G10) |
No. of Buttons |
2 |
Mass (g) |
435 |
Monotaro ID |
35172541 |
Relative Humidity |
45% to 85% |
Country of Origin |
Japan |
Case Material |
plastic |
Letters on Button |
ON (black), OFF (red) |
Rated Operating Current (A) |
0.9 |
Rated Capacity (kW) |
0.1 |
Opening / Closing Life (times) |
Electrical switching / 100,000 (220V AC, rated current 16A, switching frequency 10 times / min) |
Conformed Standard |
Electrical Appliance and Material Safety Law |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Dainichi Seisakusho Co., Ltd. |
Insulation Resistance (MOhm) |
(Between electrical circuit and box side) 10 or more |
Specifications |
waterproof |
Compatible Cable |
2 mm² |
Reference Ambient Temperature |
40℃ |
Overcurrent Tripper Type |
Thermal method |
