| Model No | DKFW233 |
| Color | Munsell N5.5 |
| Type of Product | Push Button Switch |
| Protection Class | IP67 |
Model No |
DKFW233 |
Color |
Munsell N5.5 |
Type of Product |
Push Button Switch |
Protection Class |
IP67 |
Type |
Embedded / Waterproof |
Terminal Screw |
M4 (with wire presser washer) |
No. of Buttons |
2 |
Mass (g) |
225 |
Monotaro ID |
35172374 |
Withstand voltage (V / min) |
1500(AC220/AC440) |
Country of Origin |
Japan |
Case Material |
plastic |
Letters on Button |
ON (black), OFF (red) |
Rated Operating Current (A) |
20 |
Rated Capacity (kW) |
Three-phase 220 VAC / 3.7, 440 VAC / 3.7 |
No. of Pole |
3P |
Conformed Standard |
Electrical Appliance and Material Safety Law |
Import Country |
Direct Import from Japan |
Rated Operating Voltage (V) |
AC 220/AC 440 |
Name of Manufacturer/Packer/Importer |
Dainichi Seisakusho Co., Ltd. |
Insulation Resistance (MOhm) |
(Between electrical circuit and box side) 10 or more |
Specifications |
waterproof |
Compatible Cable |
3.5 mm² |
Applicable motor (kW) |
3.7 |
Terminal Width |
9.2 mm |
