| Model No | AF16F5R-C1B |
| Type of Product | Control Push Button Switch |
| Vibration Resistance | Resonance test: Double amplitude 0.1 mm Frequency 10-55Hz / Constant vibration endurance test: Double amplitude 3.0 mm Frequency 16.7Hz |
| Protection Class | Operation section: IP65 (oil-proof type) |
Model No |
AF16F5R-C1B |
Type of Product |
Control Push Button Switch |
Vibration Resistance |
Resonance test: Double amplitude 0.1 mm Frequency 10-55Hz / Constant vibration endurance test: Double amplitude 3.0 mm Frequency 16.7Hz |
Protection Class |
Operation section: IP65 (oil-proof type) |
Return Function |
Alternate |
Withstand Voltage |
Between charging part and ground: AC2000V 1 minute, between different pole charging parts: AC2000V 1 minute (lamp terminal vs. contact terminal) |
Monotaro ID |
64022903 |
Storage Temperature |
-40 to +70℃ |
Terminal Shape |
For solder and tab (# 110) |
Button Color |
Black (black with a set of transparent button and black name plate) |
Contact Configuration |
1C |
Short Circuit Protection Device |
gG 2A (IEC60269 fuse) |
Rated Impulse Withstand Voltage (kV) |
2.5 |
Mechanical Durability |
250,000 times or more |
Pollution Degree (Environment to Use) |
3 |
Rated Insulation Voltage (V) |
AC/DC 250 |
Electrical Durability |
100,000 times or more (at AC220V 0.7A) |
Country of Origin |
Japan |
Operation Mechanism |
Round flat |
Operating Frequency |
1200 Operation/Hour (40% usage rate) |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Operation Ambient Temperature (°C) |
-10-+55 (no freezing or condensation) |
Insulation Resistance (MOhm) |
100 or more (at 500 VDC megger) |
