| Model No | AH165-V5R01 |
| Type of Product | Emergency Stop Push Button Switch |
| Vibration Resistance | Resonance test: Double amplitude 0.1 mm Frequency 10-55Hz / Constant vibration endurance test: Double amplitude 3.0 mm Frequency 16.7Hz |
| Protection Class | Operation unit: IP65F (Oil-proof large type) |
Model No |
AH165-V5R01 |
Type of Product |
Emergency Stop Push Button Switch |
Vibration Resistance |
Resonance test: Double amplitude 0.1 mm Frequency 10-55Hz / Constant vibration endurance test: Double amplitude 3.0 mm Frequency 16.7Hz |
Protection Class |
Operation unit: IP65F (Oil-proof large type) |
Return Function |
Turn reset |
Withstand Voltage |
Between charging part and ground: AC2000V 1 minute, between different pole charging parts: AC1500V 1 minute (lamp terminal vs. contact terminal) |
Monotaro ID |
64022438 |
Storage Temperature |
-40 to 70℃ |
Terminal Shape |
For solder and tab (# 110) |
Button Color |
Red |
Contact Configuration |
1B |
Short Circuit Protection Device |
Fuse 1A |
Mechanical Durability |
100,000 times or more |
Pollution Degree (Environment to Use) |
3 |
Rated Insulation Voltage (V) |
AC/DC 250 |
Electrical Durability |
100,000 times or more (at AC220V 0.7A) |
Structure |
Oil-proof type |
Country of Origin |
Japan |
Operation Mechanism |
Large push lock (Φ32) |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Operation Ambient Temperature (°C) |
-10 to 70 (no freezing or condensation) |
Insulation Resistance (MOhm) |
100 or more (at 500 VDC megger) |
Rated Frequency (Hz) |
50/60 |
Body Color |
Red |
