Fuji Electric Control Push Button Switch AC/DC 250 V Rated Insulation Voltage, AR16G0T-C1B

Name: Fuji Electric Control Push Button Switch AC/DC 250 V Rated Insulation Voltage, AR16G0T-C1B
Brand: Fuji Electric
SKU: IND.PUS.338427037
Price: 1651 INR
Availability: InStock

Visit the Fuji Electric Store

Available offers

Get Flat 10% off on your First Orders above ₹3,000

View

Get Flat 10% off on your First Order above ₹3,000

View

Get Flat 10% off on your First Order above ₹3,000

View

Get Flat 3% off on First Order above ₹3,000

View

Features

Model No	AR16G0T-C1B
Type of Product	Control Push Button Switch
Vibration Resistance	Resonance test: Double amplitude 0.1 mm Frequency 10-55Hz / Constant vibration endurance test: Double amplitude 3.0 mm Frequency 16.7Hz
Protection Class	Operation unit (display unit) protection structure: IP65 (dust-resistant / jet-proof) IEC 60529, IP65F (dust-resistant / jet-proof / oil-proof) JIS C 0920 / IP2X (fast-connecting socket AR6S690, for connectors) When socket AR6S691-C or charging part protective cover AR6Y261 is installed)

More Fuji Electric Push Button Switches products More Push Button Switches products

100% Original Products

Secure Payments

100% Buyer Protection

Top Brands

specifications

Model No	AR16G0T-C1B
Type of Product	Control Push Button Switch
Vibration Resistance	Resonance test: Double amplitude 0.1 mm Frequency 10-55Hz / Constant vibration endurance test: Double amplitude 3.0 mm Frequency 16.7Hz
Protection Class	Operation unit (display unit) protection structure: IP65 (dust-resistant / jet-proof) IEC 60529, IP65F (dust-resistant / jet-proof / oil-proof) JIS C 0920 / IP2X (fast-connecting socket AR6S690, for connectors) When socket AR6S691-C or charging part protective cover AR6Y261 is installed)
Return Function	Momentary
Withstand Voltage	Between charging part and ground: AC2000V 1 minute, between opposite pole charging part: AC2000V 1 minute
Monotaro ID	64005823
Storage Temperature	-40 to 70℃
Terminal Shape	For solder and tab (# 110)
Button Color	Black
Contact Configuration	1C
Short Circuit Protection Device	gG 2A (IEC60269 fuse)
Rated Impulse Withstand Voltage (kV)	2.5
Mounting Hole Diameter (Φmm)	16
Mechanical Durability	1,000,000 times or more
Pollution Degree (Environment to Use)	3
Rated Insulation Voltage (V)	AC/DC 250
Electrical Durability	100,000 times or more (at AC220V 0.7A)
Country of Origin	Japan
Operation Mechanism	Long square flat type with guard
Import Country	Direct Import from Japan
Name of Manufacturer/Packer/Importer	Fuji Electric Co., Ltd.
Operation Ambient Temperature (°C)	-10 to 55 (no freezing or condensation)
Insulation Resistance (MOhm)	100 or more (at 500 VDC megger)
