| Model No | AF16F0N-C1E3G |
| Type of Product | Illuminated Push Button Switch |
| Protection Class | IP65/IP65F |
| Monotaro ID | 49987007 |
Model No |
AF16F0N-C1E3G |
Type of Product |
Illuminated Push Button Switch |
Protection Class |
IP65/IP65F |
Monotaro ID |
49987007 |
Storage Temperature |
-40 to +70℃ |
Terminal Shape |
Solder terminal / tab terminal |
Button Shape |
Long angle (flat type) |
Button Color |
Green |
Contact Configuration |
1C |
Operation Type |
Momentary |
Withstand voltage (V / min) |
Between live parts and ground / between different polarity live parts: AC 2000 |
Short Circuit Protection Device |
gG 2A (IEC60269 fuse) |
Conditional Short-Circuit Current |
1000 Amp |
Mechanical Durability |
1,000,000 times or more |
Relative Humidity |
45-85% RH (at -5-+ 40°C) (with no freezing or condensation) |
Electrical Durability |
AC220V 0.7A; 100,000 times or more |
Applicable Voltage (V) |
AC/DC 24 |
Country of Origin |
Japan |
Operating Frequency |
1200 Operation/Hour (40% usage rate) |
Import Country |
Direct Import from Japan |
Illuminated Colors |
Green |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Operation Ambient Temperature (°C) |
-10-+55 (no freezing or condensation) |
Insulation Resistance (MOhm) |
100 or more (with DC 500V mega) |
Shock Resistance (m/s²) |
Malfunction: 100, Durability: 500 |
