| Model No | AR30V5L-01E3R |
| Type of Product | Pushbutton Switch |
| Insulation Resistance | Between live parts and earth/between live parts of different polarities: 100 mΩ or more (DC 500 V megger) |
| Protection Class | IP65 |
Model No |
AR30V5L-01E3R |
Type of Product |
Pushbutton Switch |
Insulation Resistance |
Between live parts and earth/between live parts of different polarities: 100 mΩ or more (DC 500 V megger) |
Protection Class |
IP65 |
Standard |
UL, CSA, TUV |
Type |
Illuminated |
Terminal Screw |
M3.5 plus/minus screw with square washer (self-lifting type) |
Monotaro ID |
50067202 |
Storage Temperature |
-40 to 80℃ |
Terminal Shape |
Screw terminal |
Button Shape |
Round (Large Push Lock) |
Button Color |
Red |
Mounting Dimensions (mm) |
Φ30.5 |
Contact Configuration |
1B |
Operation Type |
Push lock / turn reset |
Operation Ambient Temperature |
-20 to 50℃ (no freezing or condensation) |
Mechanical Durability |
100,000 times or more |
Rated Insulation Voltage (V) |
AC/DC 250 |
Light Source |
LED |
Applicable Voltage (V) |
AC/DC 24 |
Method |
All voltage type |
Country of Origin |
Japan |
Product Type |
Illuminated push button switch |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Rated Frequency (Hz) |
50/60 |
