| Model No | A30FAG2410OLE |
| Type of Product | Illuminated Switch |
| Shape | Metal guard (hole ant) type (metal ring) |
| Protection Class | IP65 oil-proof type |
Model No |
A30FAG2410OLE |
Type of Product |
Illuminated Switch |
Shape |
Metal guard (hole ant) type (metal ring) |
Protection Class |
IP65 oil-proof type |
Type |
All voltage type |
Voltage |
AC/DC 24 V |
Monotaro ID |
37850355 |
Terminal Shape |
Screw terminal |
Button Shape |
Round (Metal guard (with hole) type) |
Contact Configuration |
1A |
Operation Type |
Momentary |
Mounting Hole Diameter (Φmm) |
30.5(+0.5 to 0) |
Relative Humidity |
45 to 85% |
Rated Insulation Voltage (V) |
AC / DC600 (Lighting part: AC / DC250) |
Light Source |
LED sphere (High Bright Economy) |
Country of Origin |
Japan |
Operating Force (N) |
Approx. 11 (Contact configuration 1a1b) |
Rated Operating Current (A) |
Contact part: AC-15 class (inductive load) / 10, DC-13 class (inductive load) / 6, DC-12 class (resistive load) / 6 |
Temperature Rise |
40K or less |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Maruyasu Electric Co., Ltd. |
Operation Ambient Temperature (°C) |
-20 to 55 |
Insulation Resistance (MOhm) |
100 or more (500 V) |
Contact Resistance (ohm) |
30 mΩ or less |
Cold Resistance |
-40 to 70℃ |
Heat Resistant Temperature (℃) |
-40 to 70 |
