| Model No | DS-193-K |
| Type of Product | Push Button Switch |
| Circuits | SPST(2P) |
| Type | Non-illuminated type |
Model No |
DS-193-K |
Type of Product |
Push Button Switch |
Circuits |
SPST(2P) |
Type |
Non-illuminated type |
Switch Type |
OFF-(ON) |
Monotaro ID |
38906104 |
Terminal Shape |
Solder terminal |
Button Color |
Black |
Operation Type |
Momentary |
Mounting Hole Diameter (Φmm) |
7 |
Country of Origin |
Japan |
RoHS Directive |
Correspondence |
Import Country |
Direct Import from Japan |
Operating Patterns |
Non-lock |
Name of Manufacturer/Packer/Importer |
Miyama Electric Co., Ltd. |
Insulation Resistance (MOhm) |
100 or more (MIN)/DC500V |
Contact Resistance (ohm) |
20 mΩ or less (MAX) |
Current Capacity |
1 Amp 125 V.AC |
Isolation Voltage |
AC 1000 V for 1 minute |
Suitable Door Thickness to Mount (mm) |
1 (Manufacturer recommended value) |
