| Model No | DS-412-W |
| Type of Product | Push Button Switch |
| Circuits | SPST(2P) |
| Type | Non-illuminated type |
Model No |
DS-412-W |
Type of Product |
Push Button Switch |
Circuits |
SPST(2P) |
Type |
Non-illuminated type |
Switch Type |
OFF-(ON) |
Monotaro ID |
38905815 |
Button Color |
White |
Operation Type |
Momentary |
Mounting Hole Diameter (Φmm) |
17.8±0.1 |
Country of Origin |
Japan |
No. of Pole |
2 |
RoHS Directive |
Correspondence |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Miyama Electric Co., Ltd. |
Insulation Resistance (MOhm) |
100 or more (MIN)/DC500V |
Contact Resistance (ohm) |
20 mΩ or less (MAX) |
Current Capacity |
3 Amp 125 V.AC |
Isolation Voltage |
AC 1000 V for 1 minute |
Suitable Door Thickness to Mount (mm) |
0.7 to 2.6 |
