| Model No | MS-027-K |
| Type of Product | Push Button Switch |
| Circuits | SPST(2P) |
| Type | Non-illuminated push switch |
Model No |
MS-027-K |
Type of Product |
Push Button Switch |
Circuits |
SPST(2P) |
Type |
Non-illuminated push switch |
Switch Type |
OFF-ON |
Monotaro ID |
38905666 |
Terminal Shape |
Solder terminal |
Button Color |
Black |
Operation Type |
Alternate |
Withstand voltage (V / min) |
AC 1500 |
Mounting Hole Diameter (Φmm) |
(Reference) 12.2 |
Country of Origin |
Japan |
Rating |
3A.250 V.AC |
RoHS Directive |
Correspondence |
Mounting Hole (mm) |
(Reference) Φ12.2 |
Import Country |
Direct Import from Japan |
Operating Patterns |
Alternate |
Name of Manufacturer/Packer/Importer |
Miyama Electric Co., Ltd. |
Insulation Resistance (MOhm) |
5 or more/DC500V |
Contact Resistance (ohm) |
20 mΩ or less (MAX) |
Specifications |
The button is not displayed |
Current Capacity |
3 Amp 250 V.AC |
Isolation Voltage |
AC 1500 V for 1 minute |
