Nidek Rocker Switch AC 125/AC 250 V Rated Voltage, SL10K2-5-Z (Pack of 10)

Name: Nidek Rocker Switch AC 125/AC 250 V Rated Voltage, SL10K2-5-Z (Pack of 10)
Brand: Nidek
SKU: IND.PUS.344302862
Price: 6135 INR
Availability: InStock

Visit the Nidek Store

EMI starts at ₹545/month. No Cost EMI available.

Available offers

Get Flat 10% off on your First Orders above ₹3,000

View

Get Flat 10% off on your First Order above ₹3,000

View

Get Flat 10% off on your First Order above ₹3,000

View

Get Flat 3% off on First Order above ₹3,000

View

Features

Model No	SL10K2-5-Z
Color	(Frame locker) black
Type of Product	Rocker Switch
Service Life	(Electrical) Rush current / AC125V 100A, Breaking current / 10A: 10,000 times (Electrical) Rushing current / AC125V 60A, Breaking current / 10A: 20,000 times (Electrical) Rushing current / AC250V 60A, Breaking current / 6A : 10,000 times (electrical) inrush current / AC250V 36A, breaking current / 6A: 20,000 times (electrical) resistance load: 20,000 times

More Nidek Push Button Switches products More Push Button Switches products

100% Original Products

Secure Payments

100% Buyer Protection

Top Brands

specifications

Model No	SL10K2-5-Z
Color	(Frame locker) black
Type of Product	Rocker Switch
Service Life	(Electrical) Rush current / AC125V 100A, Breaking current / 10A: 10,000 times (Electrical) Rushing current / AC125V 60A, Breaking current / 10A: 20,000 times (Electrical) Rushing current / AC250V 60A, Breaking current / 6A : 10,000 times (electrical) inrush current / AC250V 36A, breaking current / 6A: 20,000 times (electrical) resistance load: 20,000 times
Rated Current (A)	46301
Operating Temperature Range	-25 to +85
Switch Type	ON-OFF connection terminal: (1-2, 3-4)-
Withstand Voltage	1500 VAC for 1 minute (between terminals)
Monotaro ID	37722867
Terminal Shape	Tab terminal
Country of Origin	Japan
No. of Pole	2-pole single throw
Rating	Inrush current (power factor 0.6) / AC125V 100A / 60A, AC250V 60A / 36A, breaking current (power factor 0.9) / 10A (AC125V), 6A (AC250V) Resistance load: AC125V 10A, AC250V 6A (power factor 1.0) ) Minimum rating: AC / DC5V 10mA
Rated Voltage (V)	AC 125/AC 250
RoHS Directive	Correspondence
Import Country	Direct Import from Japan
Circuit configuration	2-pole single throw
Storage Temperature Range	-40 to +85
Pack of	10 Pcs
Name of Manufacturer/Packer/Importer	Nidec Components (formerly Nidec Copal Electronics/Fujisoku)
Insulation Resistance (MOhm)	100 or more (500 V DC) (between terminals)
Contact Resistance (ohm)	(Initial) 20 or less (DC2-4 V 1A)
Specifications	Operating force: 3.92 to 12.7N
Display	・
Number Of Rows	Single throw
