| Model No | SLE10K2-7-Z |
| Color | (Frame locker) black |
| Type of Product | Rocker Switch |
| Service Life | (Electrical) inductive load: 10,000 times, resistive load: 20,000 times |
Model No |
SLE10K2-7-Z |
Color |
(Frame locker) black |
Type of Product |
Rocker Switch |
Service Life |
(Electrical) inductive load: 10,000 times, resistive load: 20,000 times |
Rated Current (A) |
46301 |
Operating Temperature Range |
-25 to +85 |
Switch Type |
ON-OFF connection terminal: (1-2, 3-4)- |
Withstand Voltage |
1500V AC for 1 minute |
Monotaro ID |
37722937 |
Terminal Shape |
Tab terminal |
Country of Origin |
Japan |
No. of Pole |
2-pole single throw |
Rating |
Inductive load: Inrush current (power factor 0.6)/AC125V 60A, AC250V 36A, Breaking current (power factor 0.9)/AC125V 10A, AC250V 6A Resistive load: AC125V 10A, AC250V 6A (power factor 1.0) Minimum rating: AC/DC5V 10mA |
Rated Voltage (V) |
AC 125/AC 250 |
RoHS Directive |
Correspondence |
Import Country |
Direct Import from Japan |
Circuit configuration |
2-pole single throw |
Storage Temperature Range |
-40 to +85 |
Pack of |
10 Pcs |
Name of Manufacturer/Packer/Importer |
Nidec Components (formerly Nidec Copal Electronics/Fujisoku) |
Insulation Resistance (MOhm) |
100 or more (DC 500 V) |
Contact Resistance (ohm) |
(Initial) 20 or less (DC2-4 V 1A) |
Specifications |
Operating force: 3.92 to 12.7N |
Display |
ON OFF |
Number Of Rows |
Single throw |
