| Model No | YB-25KKS1 |
| Type of Product | Illuminated Push Button Switch |
| Series | YB |
| Operating Temperature Range | -25/+50℃ |
Model No |
YB-25KKS1 |
Type of Product |
Illuminated Push Button Switch |
Series |
YB |
Operating Temperature Range |
-25/+50℃ |
Model Name |
YB-25KKS1 |
Monotaro ID |
68614686 |
Terminal Shape |
Solder terminal |
Country of Origin |
Japan |
Operation Mechanism |
Sold separately: 15mm square |
No. of Pole |
2-pole double throw |
RoHS Directive |
Correspondence |
Import Country |
Direct Import from Japan |
Contact Specifications |
Silver |
Mounting Hole Diameter |
Φ16 mm |
Name of Manufacturer/Packer/Importer |
NKK Switches Co., Ltd. |
Current Capacity |
【1】3A 125V AC【2】3A 250V AC【3】3A 30V DC |
Functional Operation |
ON-(ON) momentary |
Maximum Mounting Panel Thickness (mm) |
3.5 |
Mounting Method |
Snap-in |
Emitting Element |
Sold separately |
Additional Functions |
Barrier Type |
