| Model No | LP01-15CCKNS1M |
| Color | Black |
| Type of Product | Pushbutton Switch |
| Contact Material | Silver |
Model No |
LP01-15CCKNS1M |
Color |
Black |
Type of Product |
Pushbutton Switch |
Contact Material |
Silver |
Standard |
UL, C-UL |
Type |
Non-illuminated type |
Operating Temperature Range |
-10 to 50℃ |
Withstand Voltage |
AC 1000 (between terminal and terminal), AC 1500 (between terminal and ground) |
Monotaro ID |
75797714 |
Terminal Shape |
Solder |
Button Shape |
Round |
Button Color |
Green |
Contact Configuration |
Switching Contact (C Contact) |
Operation Type |
Momentary |
Mounting Hole Diameter (Φmm) |
16 |
Mechanical Durability |
500000 times or more |
Country of Origin |
Japan |
Operating Force (N) |
1.5±0.7 |
Included Components |
Socket (AT-716) |
Import Country |
Direct Import from Japan |
Operations |
Operation amount: Approx. 3 mm |
Trusco Part No. |
438-5063 |
Name of Manufacturer/Packer/Importer |
NKK Switches Co., Ltd. |
Insulation Resistance (MOhm) |
200 or more (DC 500 V) |
Contact Resistance (ohm) |
50 or less (DC2-4V at 100mA) |
Heat Resistance |
When using a soldering iron: Tip temperature: 390°C or less; Soldering time: 4 seconds or less; Number of times: 2 times (after returning to room temperature) |
