Ships within 25 days
View
View
View
View
| Model No | A3AT-91B1-00B |
| Type of Product | Small Pushbutton Switch |
| Protection Class | IEC IP40 |
| Type | Small pushbutton switch |
Model No |
A3AT-91B1-00B |
Type of Product |
Small Pushbutton Switch |
Protection Class |
IEC IP40 |
Type |
Small pushbutton switch |
Mass (g) |
About 3.2 |
Monotaro ID |
66543435 |
Storage Temperature |
-25 To 65℃ (No Freezing Or Condensation) |
Terminal Shape |
Printed Circuit Board Terminal |
Contact Configuration |
1C |
Operation Type |
Alternate |
Mechanical Durability |
50,000 times or more (once set or reset) |
Electrical Durability |
50,000 times or more |
Country of Origin |
JAPAN |
Electric Shock Protection Class |
Class Ⅱ |
PTI (Proof Tracking Index) |
175 |
Terminal Type |
PCB terminal |
Type of Illumination |
Non-illuminated |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-10 to 55 (no freezing or condensation) |
Insulation Resistance (MOhm) |
100 Or More (With Dc500V Insulation Resistance Meter) |
Contact Resistance (ohm) |
100 mΩ or less (Initial Value) |
Specifications |
Confirm Delivery Date Each Time |
Stroke (mm) |
Lock stroke LTA: Min. 0.5 |
Safety Standard |
Ul(File No. E41515), Csa(File No. Lr45258), Ccc(Gb/T14048.5) |
Remark |
Confirm Delivery Date Each Time |
