| Model No | B3W-9000-B1C |
| Type of Product | Illuminated Tactile Switch |
| Type | B3W-9000 series standard load type |
| Operating Temperature Range | -25 to +70℃ 60% RH or less ( However, there should be no freezing or condensation) |
Model No |
B3W-9000-B1C |
Type of Product |
Illuminated Tactile Switch |
Type |
B3W-9000 series standard load type |
Operating Temperature Range |
-25 to +70℃ 60% RH or less ( However, there should be no freezing or condensation) |
Shock Resistance |
Up to 1000 ( m/s² ) |
Part No |
64-3343-01 |
Withstand Voltage |
AC500V 50/60Hz 1min |
Monotaro ID |
46542955 |
Contact Configuration |
1A (Normally Open Contact) |
Country of Origin |
CHINA |
Operating Force (N) |
Up to 1.57 |
Rating |
DC 3-24 V 1-50 mA |
Minimum Applicable Load |
DC 1 V 10μA (reference Value) |
LED Color |
Blue (high brightness) |
Import Country |
Direct Import from Japan |
Vibration Resistance (Malfunction) |
10-55Hz double amplitude 1.5mm |
Shock Resistance (Malfunction) |
Up to 100 (m / s² ) |
Durability |
Switch part 1 million times or more |
Operating Humidity Range |
35 to 85% RH (at 5 to 35 ° C) |
Cap Color |
Transparent |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Height (mm) |
11 |
Insulation Resistance (MOhm) |
100 or more (with DC250V insulation resistance meter) |
Contact Resistance (ohm) |
100 mΩ or less (initial value) |
Number of LED (pieces) |
1 |
