| Model No | A8A-223-2 |
| Type of Product | Rocker Switch |
| Protection Class | IEC IP40 |
| Type | Rocker switch |
Model No |
A8A-223-2 |
Type of Product |
Rocker Switch |
Protection Class |
IEC IP40 |
Type |
Rocker switch |
Allowable Operating Speed |
1 to 500 mm/s |
Mass (g) |
About 16 |
Monotaro ID |
46490166 |
Mechanical Durability |
40,000 times or more |
Electrical Durability |
20,000 times or more |
Country of Origin |
JAPAN |
Electric Shock Protection Class |
Class Ⅱ |
Rated Voltage (V) |
AC 200 to 220 |
Type of Illumination |
Neon light |
Import Country |
Direct Import from Japan |
Lamp Voltage (V) |
AC250 |
Cap Color |
Green |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-20 to 50 (no freezing or condensation) |
Insulation Resistance (MOhm) |
100 Or More (With Dc500V Insulation Resistance Meter) |
Contact Resistance (ohm) |
20 mΩ or less (DC 6-8V, 1A voltage drop method) (initial value) |
Specifications |
Confirm Delivery Date Each Time |
Safety Standard |
Ul(Ul508), Csa(Csa C22.2 No.55), Vde(En61058-1) |
Display |
No marking |
Remark |
Confirm Delivery Date Each Time |
Ambient Humidity (% RH) |
45-85 or less |
