Ships within 25 days
View
View
View
View
| Model No | A16-JWM-1P |
| Type of Product | Push Button Switch |
| Contact Type | Double throw type (c contact) |
| Protection Class | Ip40 |
Model No |
A16-JWM-1P |
Type of Product |
Push Button Switch |
Contact Type |
Double throw type (c contact) |
Protection Class |
Ip40 |
Type |
Pushbutton switch (separate type) |
Monotaro ID |
46667957 |
Storage Temperature |
-25 To 65 ℃ (No Freezing Or Condensation) |
Contact Configuration |
1C |
Operation Type |
Momentary |
Mechanical Durability |
2 million times or more |
Pollution Degree (Environment to Use) |
3(IEC60947-5-1) |
Electrical Durability |
100,000 times or more |
Country of Origin |
JAPAN |
Electric Shock Protection Class |
Class Ⅱ |
PTI (Proof Tracking Index) |
175 |
Terminal Type |
PCB terminal |
Type of Illumination |
Non-illuminated |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-10 to 55 (no freezing or condensation) |
Insulation Resistance (MOhm) |
100 mΩ Or More (With DC 500 V Mega) |
Contact Resistance (ohm) |
100 mΩ or Less (initial value) |
Specifications |
Confirm Delivery Date Each Time |
