Ships within 19 days
Model No
View
View
View
View
| Model No | A165E-01L |
| Type of Product | Push Button Switch |
| Operating Force | Up to 14.7 N (standard value) |
| Shape | Separate type |
Model No |
A165E-01L |
Type of Product |
Push Button Switch |
Operating Force |
Up to 14.7 N (standard value) |
Shape |
Separate type |
Function |
Non-illuminated, push-lock turn reset |
Ambient Humidity to Use |
35 to 85%Rh |
Monotaro ID |
38970285 |
Contact Configuration |
1B |
Mounting Hole Diameter (Φmm) |
16 |
Mechanical Durability |
100,000 times or more |
Pollution Degree (Environment to Use) |
Pollution degree 3 (EN60947-5-1) |
Light Source |
Non-illuminated |
Country of Origin |
Japan |
Electric Shock Protection Class |
Class Ⅱ |
PTI (Proof Tracking Index) |
175 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-10 to +55 (with no icing or condensation) |
Insulation Resistance (MOhm) |
100 mΩ Or More (With DC 500 V Mega) |
