| Model No | A22-DG-01M |
| Type of Product | Pushbutton Switch |
| Protection Class | IP65 |
| Type | Push button switch |
Model No |
A22-DG-01M |
Type of Product |
Pushbutton Switch |
Protection Class |
IP65 |
Type |
Push button switch |
Shock Resistance |
Up To 1000 m/s² |
Withstand Voltage |
Between homopolar terminals, between each terminal and ground: 2500 V AC 50/60 Hz for 1 min |
Ambient Humidity to Use |
35 to 85%Rh |
Monotaro ID |
38992125 |
Storage Temperature |
-40 to +70 ℃ (with no icing or condensation) |
Terminal Shape |
Screw terminal |
Button Shape |
Corner (guard type) |
Button Color |
Green |
Contact Configuration |
1B |
Operation Type |
Momentary |
Country of Origin |
JAPAN |
Allowable Operation Frequency |
Mechanical: Up to 60 times / min, Electrical: 30 times / min |
Terminal Type |
Screw terminal (M3.5) |
Type of Illumination |
Non-illuminated |
Import Country |
Direct Import from Japan |
Vibration Resistance (Malfunction) |
10 to 55 Hz, double amplitude 1.5mm (malfunction 1ms) |
Shock Resistance (Malfunction) |
1000 m/s² (Malfunction 1Ms Or Less) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-20 to +70 (with no icing or condensation) |
Insulation Resistance (MOhm) |
100 mΩ Or More (With DC 500 V Mega) |
Contact Resistance (ohm) |
100 mΩ or Less (initial value) |
