| Model No | B3W-4055S |
| Type of Product | Seal Type Tactile Switch |
| Operating Force | 3.43{350gf} N |
| Type | 12 mm square B3W-4000 series (plunger: flat type) |
Model No |
B3W-4055S |
Type of Product |
Seal Type Tactile Switch |
Operating Force |
3.43{350gf} N |
Type |
12 mm square B3W-4000 series (plunger: flat type) |
Part No |
64-3342-93 |
Withstand Voltage |
AC 500 V 50/60 Hz 1 min |
Monotaro ID |
46445795 |
Contact Configuration |
1A |
Country of Origin |
CHINA |
Rating |
DC 5 to 24 V 1 to 50 mA (resistive load) |
Import Country |
Direct Import from Japan |
Shock Resistance (Malfunction) |
100 m/s² {approx.10G}max. |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Insulation Resistance (MOhm) |
100min.(at DC 250 V) |
Shock Resistance (m/s²) |
1000{approx.100G}max. |
Bouncing |
5 ms max. |
Earth Terminal |
None |
Vibration (Malfunction) |
10-55 Hz, double amplitude 1.5 mm |
