Ships within 25 days
Contact Configuration
Terminal Type
Model No
View
View
View
View
| Model No | A16-TAM-2S |
| Type of Product | Pushbutton Switch |
| Insulation Resistance | 100 mΩ or more (with DC500 V mega) |
| Protection Class | IP40 |
Model No |
A16-TAM-2S |
Type of Product |
Pushbutton Switch |
Insulation Resistance |
100 mΩ or more (with DC500 V mega) |
Protection Class |
IP40 |
Shock Resistance |
500 m/s² |
Withstand Voltage |
Between Homopolar Terminals: 1000 VAC 50/60 Hz for 1 min / Between Different Polarity Terminals, Between Each Terminal and Ground: 2000 VAC 50/60 Hz for 1 min |
Ambient Humidity to Use |
35~85%RH |
Monotaro ID |
38989526 |
Storage Temperature |
-25 to +65°C (With No Icing or Condensation) |
Button Shape |
Round (Protruding) |
Button Color |
Blue |
Contact Configuration |
2c |
Operation Type |
Momentary |
Operation Ambient Temperature |
-10 to +55°C (With No Icing or Condensation) |
Country of Origin |
JAPAN |
Terminal Type |
Quick Connector |
Type of Illumination |
Non-Illuminated |
Import Country |
Direct Import from Japan |
Mounting Hole Diameter |
Φ16 mm |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
