| Model No | A16L-TRM-T2-2S |
| Type of Product | Pushbutton Switch |
| Insulation Resistance | 100 mΩ or more (with DC500 V mega) |
| Shape | Round |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Model No |
A16L-TRM-T2-2S |
Type of Product |
Pushbutton Switch |
Insulation Resistance |
100 mΩ or more (with DC500 V mega) |
Shape |
Round |
Protection Class |
IP40 |
Withstand Voltage |
Between Homopolar Terminals, Between Lamp Terminals: 1000 VAC 50/60 Hz for 1 min / Between Different Polarity Terminals, Between Each Terminal and Ground: 2000 VAC 50/60 Hz for 1 min |
Monotaro ID |
38988354 |
Storage Temperature |
-25 to +65°C (With No Icing or Condensation) |
Button Shape |
Round (Protruding) |
Contact Configuration |
2c |
Operation Type |
Momentary |
Light Source |
LED |
Applicable Voltage (V) |
AC/DC220 |
Country of Origin |
JAPAN |
Terminal Type |
Quick Connector |
Type of Illumination |
Illumination (LED (Built-In Reduced Pressure Illumination Function)) |
Lamp Voltage (V) |
AC/DC 220 |
Mounting Hole Diameter |
Φ16 mm |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
