| Model No | A3AT-91K1-00H |
| Type of Product | Small Pushbutton Switch |
| Protection Class | IEC IP40 |
| Type | Small pushbutton switch |
Model No |
A3AT-91K1-00H |
Type of Product |
Small Pushbutton Switch |
Protection Class |
IEC IP40 |
Type |
Small pushbutton switch |
Shock Resistance |
500 m/s² |
Mass (g) |
About 3.2 |
Withstand Voltage |
Between homopolar terminals: AC 600 V 50 / 60 Hz 1min / Between each terminal and ground: AC2000V 50 / 60Hz 1min |
Ambient Humidity to Use |
35 to 85%Rh |
Monotaro ID |
46694417 |
Storage Temperature |
-25 To 65℃ (No Freezing Or Condensation) |
Terminal Shape |
Printed Circuit Board Terminal |
Contact Configuration |
1A |
Operation Type |
Momentary |
Country of Origin |
Japan |
Terminal Type |
PCB terminal |
Type of Illumination |
Non-illuminated |
Import Country |
Direct Import from Japan |
Vibration Resistance (Malfunction) |
10 to 55 Hz, double amplitude 1.5mm (malfunction 1ms) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-10 to 55 (no freezing or condensation) |
Insulation Resistance (MOhm) |
100 Or More (With Dc500V Insulation Resistance Meter) |
Contact Resistance (ohm) |
100 mΩ or less (Initial Value) |
Specifications |
Confirm Delivery Date Each Time |
Safety Standard |
Ul(File No. E41515), Csa(File No. Lr45258), Ccc(Gb/T14048.5) |
Remark |
Confirm Delivery Date Each Time |
