Ships within 19 days
View
View
View
View
| Model No | B3SN-3112 |
| Color | (Plunger) Ivory |
| Type of Product | Sealed Surface Mount Tactile Switch |
| Operating Force | 1.57±0.49 N |
Model No |
B3SN-3112 |
Color |
(Plunger) Ivory |
Type of Product |
Sealed Surface Mount Tactile Switch |
Operating Force |
1.57±0.49 N |
Type |
6 mm square B3W-3000 series |
Part No |
64-3342-72 |
Mass (g) |
About 0.2 |
Withstand Voltage |
AC 250 V 50/60 Hz 1 min |
Ambient Humidity to Use |
35 to 85% RH (at +5 to + 35 ° C) |
Monotaro ID |
39029347 |
Contact Configuration |
1a (normally open contact) |
Country of Origin |
Japan |
Return Force (N) |
Min 0.29 min |
Rating |
DC3 to 24 V + 1 to 50mA + Resistive load |
Import Country |
Direct Import from Japan |
Vibration Resistance (Malfunction) |
10 to 55Hz double amplitude 1.5 mm |
Durability |
100,000 times or more |
Pretravel (PT) |
0.25±0.15 mm |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-25 to +70 60% RH or less (no freezing or condensation) |
Insulation Resistance (MOhm) |
100 or more (at 250 V DC mega) |
Contact Resistance (ohm) |
100 mΩ or Less (initial value) (DC 5 V 1mA energized) |
Shock Resistance (m/s²) |
Up to 1000 |
Bouncing |
5 ms or less |
Earth Terminal |
Included |
