Ships within 19 days
Model No
View
View
View
View
| Model No | A3AT-90B1-00L |
| Type of Product | Small Pushbutton Switch |
| Contact Type | Double throw type |
| Protection Class | IEC IP40 |
Model No |
A3AT-90B1-00L |
Type of Product |
Small Pushbutton Switch |
Contact Type |
Double throw type |
Protection Class |
IEC IP40 |
Type |
Round Type Small Square Body |
Series |
A3A Series |
Mass (g) |
About 3.2 |
Monotaro ID |
66543243 |
Storage Temperature |
-25 to 65℃ (no freezing or condensation) |
Terminal Shape |
Solder Terminal |
Contact Configuration |
1c |
Operation Type |
Alternate |
Mechanical Durability |
50,000 times or more (once set or reset) |
Electrical Durability |
50,000 times or more |
Country of Origin |
Japan |
Electric Shock Protection Class |
Class Ⅱ |
PTI (Proof Tracking Index) |
175 |
Terminal Type |
Solder terminal |
Type of Illumination |
Non-illuminated |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-10 to 55 (no freezing or condensation) |
Insulation Resistance (MOhm) |
100 or more (with DC500 V insulation resistance meter) |
Contact Resistance (ohm) |
100 or less (initial value) |
Stroke (mm) |
Lock stroke LTA: Min. 0.5 |
Safety Standard |
UL(File No. E41515), CSA(File No. LR45258), CCC(GB/T14048.5) |
