| Model No | B3F-3102 |
| Color | (Plunger) Yellow |
| Type of Product | Tactile Switch |
| Operating Force | 1.47 N |
Model No |
B3F-3102 |
Color |
(Plunger) Yellow |
Type of Product |
Tactile Switch |
Operating Force |
1.47 N |
Actuator Type |
Plunger |
Dimension (mm) |
6.25x7.3x7.4 |
Shape |
Blancja flat type |
Contact Material |
Gold plating |
Type |
6 mm side push type |
Series |
B3F-3000 series |
Mass (g) |
About 0.25 |
Withstand Voltage |
AC 500 V 50/60 Hz 1 min |
Ambient Humidity to Use |
35 to 85% RH (at +5 to + 35 ° C) |
Monotaro ID |
39028981 |
Contact Configuration |
1a (normally open contact) |
Country of Origin |
JAPAN |
Return Force (N) |
Min 0.49 min |
Rating |
DC 3 to 24 V + 1 to 50 mA + Resistance Negative |
Import Country |
Direct Import from Japan |
Vibration Resistance (Malfunction) |
10 to 55 Hz Double Amplitude 1.5 mm |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Height (mm) |
3.15 |
Operation Ambient Temperature (°C) |
-25 to +70 60% RH or less (no freezing or condensation) |
Insulation Resistance (MOhm) |
100 or more (at 250 V DC mega) |
Contact Resistance (ohm) |
100 mΩ or less (initial value) (DC 5 V 1mA energized) |
Earth Terminal |
Included |
