| Model No | BL83111 |
| Type of Product | Push Button |
| Type | 3F |
| Terminal Screw | 2-3.5 (standard compatible, round crimp terminal), 1.2 N m (12.2 kgf cm) (appropriate tightening torque) |
Model No |
BL83111 |
Type of Product |
Push Button |
Type |
3F |
Terminal Screw |
2-3.5 (standard compatible, round crimp terminal), 1.2 N m (12.2 kgf cm) (appropriate tightening torque) |
No. of Buttons |
3 |
Part No |
BL83111 |
Monotaro ID |
37612906 |
Contact Configuration |
1a+1a+1b |
Country of Origin |
Japan |
Case Material |
Plastic |
Letters on Button |
FOR (black), STOP (red), REV (black) |
Connectable Wire (mm2) |
2 (stranded wire), 1.6 mm (single wire) |
Rated Capacity (kW) |
(Supply / Shutoff Current) 1.25 |
Rating |
50 Hz / 60 Hz (frequency), 600V (insulation voltage) |
Opening / Closing Life (times) |
(Electrical) 500,000 Or More / (Mechanical) 5 Million Or More (Opening / Closing Frequency 1200 Times / Hour) |
Opening & Closing Time |
Opening and closing: 5, throwing: 100 (1 in 10 seconds) times |
Power Factor |
(Supply / Cut-Off Current) 0.6 To 0.7 |
Tightening Torque (Nm) |
(Standard) 0.8-1.2 |
Conformed Standard |
JIS C4521 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Screw Dimension |
M3.5 |
Current Capacity |
(Built-In / Shut-Off Current) 200V - 50, (Contact) Ac250V Or Less / 5, Ac600V Or Less / 3 Amp |
