| Model No | CE05-2A20-4PD-D |
| No. of Pole | 4 |
| Monotaro ID | 29473720 |
| Type of Product | Box Receptacle |
Model No |
CE05-2A20-4PD-D |
No. of Pole |
4 |
Monotaro ID |
29473720 |
Type of Product |
Box Receptacle |
Type |
Round Type |
Rated Voltage (V) |
AC 250 |
Color |
(Outer Shell) Black |
Rated Current (A) |
23 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Shape |
Straight |
Name of Manufacturer/Packer/Importer |
Fujikura (formerly DDK/Daiichi Electronics Industries) |
Pack of |
10 Pcs |
Dimension H (Φmm) |
15.88 Or More |
Dimension F (Φmm) |
14.2(±1) |
Insulation Resistance (MOhm) |
5000 or more (DC 500 V) |
Dimension B (Φmm) |
19.05(+0.97/-0.05) |
Surface Treatment |
(Outer Shell) Trivalent Chromate |
Dimension E (Φmm) |
30.6 mm (±0.5) |
Dimension L (mm) |
3.05(+0.25/-0.12) |
Dimension K |
38.1 mm (±0.5) |
Withstand Voltage |
AC 2800V (1 minute) |
Specifications |
Inverted core |
Operating Temperature (c) |
-55 to +125℃ |
Current Capacity (Amps) |
Up to 23 (per Contact) (comprehensive connector) 62.5 |
Dimension J (mm) |
29.36(±0.12) |
Dimension C |
2.75 mm (±0.35) |
