| Model No | NAW244RM |
| No. of Pole | 4 |
| Monotaro ID | 18681399 |
| Type of Product | Panel Receptacle |
Model No |
NAW244RM |
No. of Pole |
4 |
Monotaro ID |
18681399 |
Type of Product |
Panel Receptacle |
Type |
Round type |
Rated Voltage (V) |
250 |
Rated Current (A) |
15 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Shape |
Straight |
Name of Manufacturer/Packer/Importer |
Nanaboshi Scientific Research Institute Co., Ltd. |
Connection Method |
Crimping |
Contact Type |
Male |
Connection Type |
Screw |
Shell Size |
24 |
RoHS Directive |
Correspondence |
Operating Temperature Range |
-25 to +85℃ |
Insulator Material |
Synthetic resin |
Material (Gasket) |
Synthetic rubber |
Lock |
One-touch lock method |
Material/Finish |
Shell: Zinc alloy / Special treatment, Insulator: Synthetic resin, Contact: Copper alloy / Silver plating, Packing: Synthetic rubber |
Connector Type |
NAW244PF□ |
Withstand voltage (V / min) |
1500 |
Waterproof Specifications |
IP-67 equivalent |
